Sangiacomo T 30 CE Eccentric press
$ 18,829
| Type: | Buy-It-Now |
| Location: | Spain |
| Category: | Eccentric Presses |
| Manufacturer: | Sangiacomo |
| Model: | T 30 CE |
| Year of Make: | 2002 |
| Description: | Nominal force: 300 kN, |Nominal stroke: 2.6 mm, |Stopping position: P.M.S, |Adjustable travel: 9-76 mm, |Sliding adjustment: 60 mm, |Stopping time: 129 ms, |Safety distance (1.6 m / s): 174 mm, |Cycles per minute: 145, |Table dimensions: 300x500, |Max closed die height: 307.5 mm, |Min closed die height: 274 mm, |Base carriage: 40 kg, |Turns / min handwheel: 145, |Max insections / min: 60, |Total installed power: 2.25 kW, |Supply voltage: 220 V, |Auxiliary circuit voltage: 24 V, |Working air pressure: 5.5 - 6 Bar, |Weight: 1000kg, |Year of manufacture: 2002 |
| Technical Specifications: | Power in tons: 30 T Table length: 500.0 mm Table width: 300.0 mm Ram stroke: 76.0 mm Motor power: 2.3 kW Length x width x height: - × - × - Weight: 1000.0 kg State: revised At local norms: --------- |
