Soraluce TR1-1600 Radial drilling machine
$ 7,960
| Type: | Buy-It-Now |
| Location: | Spain |
| Category: | Radial Drilling Machines |
| Manufacturer: | Soraluce |
| Model: | TR1-1600 |
| Description: | This used Soraluce brand TR1-1600 flag drill has the following technical characteristics: | Max. of Drilling in Steel: 60 mm | Max. of Threaded in Steel : 50 mm | Max. of Drilling in Foundry: 80 mm |Diameter of the Column: 380 mm |Useful arm from column edge: 1,639 mm |Maximum spindle-base distance: 1,575 mm |Minimum spindle-base distance: 350 mm |Morse Cone: No. 5 |Spindle motor: 7.5 HP |Speeds No. Speeds: 12 Speeds |RPM range: 24-1,210 rpm |No. of Advances: 6 Advances |Range of Advances: 0.05 - 0.70 mm / rpm |Included Table |Dimensions of the table: 1,650 x 700 mm |Weight of the Machine: 5.600 Kg. |
| Technical Specifications: | Drilling Ø: 60.0 mm Table length: 1650.0 mm Table width: 700.0 mm Spindle speed: 210 rpm Spindle taper: Morse 5 Throat: 1575.0 mm Power: 5.6 kW Arm length: 1639.0 mm Length x width x height: - × - × - Weight: 5600.0 kg State: revised At local norms: --------- |
