Amutio Cazeneuve HB 725x1000 lathe
$ 27,646
| Type: | Buy-It-Now |
| Location: | Spain |
| Category: | Lathes |
| Manufacturer: | AMUTIO CAZENEUVE |
| Model: | HB 725x1000 |
| Description: | Rebuilt lathe |Diameter admitted on bed: 725 mm. |Diameter admitted on carriage: 670 mm. |Diameter admitted on cross slide: 400 mm. |Height of centers: 315 mm. |Distance between centers: 1000 mm. |Spindle bore: 81 mm. |Number of spindle axis speeds: 18. |Tailstock cone: CM-6 |Width of the bed: 505 mm. |Engine power: 25-20-15-10 CV. |Weight of the machine: 2300 kg. |Dimensions of the machine: 2405x1270x1355 mm. |Equipped with new universal MQD plate of 315 mm. |Protections in plate and carriage and CE certificate (RD 1215/97). |Optional window. |Rear protection type fairing optional. |Optional viewer |
| Technical Specifications: | Length between centers: 1000.0 mm Turning length: 1000.0 mm Ø above the bed: 725.0 mm Ø above transversing slide: 400.0 mm Spindle bore: 81.0 mm Overhauled: yes Year of overhauling: 2018.0 Length x width x height: - × - × - Weight: - State: rebuilt At local norms: --------- Status: visible |
