Harrison Alpha 1400XT cnc lathe
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | United Kingdom |
| Category: | CNC Lathes |
| Manufacturer: | Harrison |
| Model: | 1400XT |
| Year of Make: | 2007 |
| Description: | Used Alpha 1400XT CNC/Manual Lathe with 400mm swing x 1250mm between centres. Spindle bore 55mm. Equipped with Fanuc X Series Control, 3 jaw chuck, Parat toolpost, interlocked guarding, coolant system, lighting.|Specification |Used Harrison Alpha 1400XT CNC Lathe |Distance between centres 1250mm |Floor to spindle centres 1086mm |Swing over bed (saddle wings) 400mm |Swing over cross slide 246mm |Swing in gap 585mm |Gap width from faceplate 165mm |Spindle bored to pass 55mm |Spindle nose Camlock D1-6 |Taper in nose bush No. 4 MT |Spindle speeds: low range 1-297rpm |medium range 1-861rpm |high range 1-2700rpm |Tailstock quill travel 140mm |Tailstock quill diameter 73mm |Tailstock taper No. 5 MT |Overall length 2900mm |Overall width 1700mm |Overall height 1500mm |Approximate weight 2200kg |Used Harrison Alpha 1400XT CNC/Manual Centre Lathe|Machine Equipped with |Fanuc Alpha X Series Control |3 jaw chuck |PARAT toolpost |4-off toolholders |Electrically interlocked |
| Technical Specifications: | Ø above the bed: 400.0 mm Ø above transversing slide: 246.0 mm Length between centers: 1250.0 mm Type of CNC: Fanuc Alpha X Spindle taper: Camlock D1-6 Spindle bore: 55.0 mm Turning speed: 2700 rpm Tailstock: no Bar feeder: no Length x width x height: 2900.0 mm × 1700.0 mm × 1500.0 mm Weight: 2200.0 kg State: good At local norms: --------- |
