ECOCA EL 5115 cnc lathe
$ 12,717
| Type: | Buy-It-Now |
| Location: | Netherlands |
| Category: | CNC Lathes |
| Manufacturer: | Ecoca |
| Model: | EL 5115 |
| Year of Make: | 1997 |
| Description: | Swing over bed 510 mm |ControlSIEMENS SINUMRIK |Swing over cross slide 300 mm |Distance between centres 1500 mm |Work piece weight 500 kg |Spindle bore 85 mm |Spindle speeds / ranges 2000 Rpm |Power 11 Kw |DIMENSIONS |Length 3600 mm |Width 1950 mm |Height 1820 mm |
| Technical Specifications: | Ø above the bed: 510.0 mm Ø above transversing slide: 300.0 mm Length between centers: 1500.0 mm Type of CNC: Siemens Sinumrik Max workpiece weight: 500.0 kg Spindle bore: 85.0 mm Turning speed: 2000 rpm Spindle motor power: 11.0 kW Tailstock: no Bar feeder: no Length x width x height: 3600.0 mm × 1950.0 mm × 1820.0 mm Weight: - State: good At local norms: --------- Status: visible |
