GMW HL 1070 x 2000 cnc lathe
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Germany |
| Category: | CNC Lathes |
| Manufacturer: | GMW |
| Model: | HL 1070 x 2000 |
| Year of Make: | 2018 |
| Description: | turning diameter 1070 mm |turning length 2300 mm |control Siemens 828 D |turning diameter over slide rest 680 mm |spindle turning speed range 1 - 800 U/min |longitudinal feeds: 0,001-500 mm/rev |cross feeds: 0,001-500 mm/rev |spindle passage 153 mm |rapid travel - longitudinal/face 10/8 m/min |switching steps 4 |face slide travel 580 mm |max. workpiece weight between centres 8000 kg |total power requirement 22/26 kW |weight of the machine ca. 12,3 t |dimensions of the machine ca. 6,9 x 2,7 x 2,6 m |
| Technical Specifications: | Turning length: 2300.0 mm Turning Ø: 1070.0 mm Ø above transversing slide: 680.0 mm Type of CNC: CNC Siemens 828 Dsl Max workpiece weight: 8000.0 kg Spindle motor power: 22.0 kW Tailstock: no Bar feeder: no Length x width x height: 6900.0 mm × 2700.0 mm × 2600.0 mm Weight: 12300.0 kg State: new At local norms: yes Status: under power |
