KIEFEL KLS 70/125 K Thermoforming - laminating Machine
$ 18,717
| Type: | Buy-It-Now |
| Location: | Germany |
| Category: | Thermoforming Machines |
| Manufacturer: | Kiefel |
| Model: | KLS 70/125 K |
| Year of Make: | 1993 |
| Description: | Laminating |Form surface max. 700 x 1250 mm |minute 350 x 650 mm |Max. Molding height 150 mm positive (with slot car / shuttle) |Foil width max. 800 mm |Sheet level above floor mm 1435 |Table force upper table 30 kN |Table force undercounter 30 kN |Operating voltage 3 x 400 V + N + PE / 50 Hz |Connected load 117 kVA |Required space ca. 11,000 x 6,000 mm (length x width) Height 4,800 mm |Top heater quartz heater small 125 x 65 mm |- Underheater quartz radiator small 125 x 65 mm |Both radiators single control via monitor |- 2 x slide Cart |- Motorized width adjustment of the film transport rails |- Top table with 4-position turret, fast locking, auxiliary cylinder |- 6-fold cooling fan |- Vacuum pump with boiler |- Motor Folienabrollvorrichtung |- Control Siemens S5 |
| Technical Specifications: | Length x width x height: - × - × - Weight: 9500.0 kg State: good At local norms: yes Status: visible |
