Dean Smith & Grace Type 25 x 120 heavy duty lathe
$ 35,233
| Type: | Buy-It-Now |
| Location: | United Kingdom |
| Category: | Lathes |
| Manufacturer: | Dean Smith & Grace |
| Model: | Type 25 x 120 |
| Year of Make: | 1985 |
| Description: | DEAN SMITH & GRACE GAP BED CENTRE LATHE|Type 25 x 120 |Serial number 41971-10-85|CAPACITY |Distance between centres 120 |Swing over bed 27.25 |Swing over saddle 18.25 |Swing in gap 46.5 |Width of gap 15.37|UNIVERSAL GEARBOX |Longitudinal feeds per rev (48) 0.0014 - 0.08 in |Cross feeds half long. feeds |Threads per inch (48) 2 - 112 tpi |Inch pitches (39) 0.156 - 8 |Metric pitches (52) 0.5 - 200 mm|HEADSTOCK |Spindle speeds 7.4 600 rpm |Main motor 15 kW (20 HP) |Bore through spindle 4.125|TAILSTOCK |Spindle diameter 4.00 |Taper of centre No. 5 Morse|SADDLE & APRON |Cross slide travel 20.75 |Compound slide travel 7.00 |Leadscrew diameter 2.25 |Leadscrew pitch 0.5|Machine complete with :- |NEWALL DP700 D.R.O., 18 3-jaw chuck, 20 4-jaw chuck, 18 3 point roller steady, 10 3 point roller steady, 6 travelling steady, Taper turning, Rapid power traverse, 4 Way toolpost, Dual dials, Power drilling, Travelling sward guard, Low volt light, Coolant. |
| Technical Specifications: | Length between centers: 3048.0 mm Turning length: 3048.0 mm Ø above the bed: 693.4 mm Ø above transversing slide: 464.8 mm Diameter in the gap: 1181.1 mm Spindle bore: 101.6 mm Turning speed: 600 rpm Spindle motor power: 14.9 kW Overhauled: no Length x width x height: - × - × - Weight: - State: excellent At local norms: --------- Status: under power |
