Imatec SFP45 Sliding table saw
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Italy |
| Category: | Sliding Table Saws |
| Manufacturer: | Imatec |
| Model: | SFP45 |
| Year of Make: | 2018 |
| Description: | DOUBLE END SQUARING MACHINE AT 45 OR OTHERS DEGREE - with 3+3 motors Mod. SFP45|DIMENSIONS OF PIECES mm: |Length min. 220 max 1200 |Width min. 80 max 150 |Thickness min. 6 max 100 |Distance between feeder pistons mm 350 |FEED: |Speed of feed 4 24 mt/min |Motor of feed KW 3 |Motors for opening of machine HP 0,5 +0,5 |COLUMNS FOR OPERATING GROUPS: |Column for operating groups right for upper and lower truck (girdle), superior supporting table for |pressure. |Sliding column for operating groups on right moving upright on skids in anti-seize material with low |friction coefficient, suitably lubricated automatically by pump oil. |Column for operating groups left for upper and lower truck (girdle), superior supporting table for |pressure. |INFERIOR CHAIN TRUCKS OF FEED: |Inferior chain trucks of feed composed by elements of precision links in treated and rectified steel, |connected to each others by cylindrical intermediate junction elements in temperate steel. |Cleaning |
| Technical Specifications: | Carriage length: 1200.0 mm Max. cutting width: 150.0 mm Length x width x height: - × - × - Weight: - State: new At local norms: yes Status: visible |
