Automatic fine blanking press FEINTOOL GKPF 50/80
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Lithuania | Vilnius |
| Category: | Metal Presses |
| Manufacturer: | Feintool AG |
| Year of Make: | 1976 |
| Description: | Shearing force: 50 tons|Total force: 80 tons|Force for pushing out/presure of pump: 2-4 tons|Front passage between the columns: 450 mm|Upper plate: 420x420 mm|Bottom plate: 470x430 mm|Moving of upper plate: 80 mm|-In bottom: 11 mm|-Of pushing out: 8 mm|Max steel thickness: 5 mm|Max width of band: 180 mm|Electricity: 380V / 50Hz|Main motor: 12 kW|-Length: 1800 mm|-Width: 1600 mm|-Height: 2400 mm|Machine weight: 6000 kg |
| Technical Specifications: | Shearing force: 50 tons Total force: 80 tons Force for pushing out/presure of pump: 2-4 tons Front passage between the columns: 450 mm Upper plate: 420x420 mm Bottom plate: 470x430 mm Moving of upper plate: 80 mm -In bottom: 11 mm -Of pushing out: 8 mm Max steel thickness: 5 mm Max width of band: 180 mm Electricity: 380V / 50Hz Main motor: 12 kW -Length: 1800 mm -Width: 1600 mm -Height: 2400 mm Machine weight: 6000 kg |
