Combined bed-type milling machine 6640-0-2
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Lithuania | Vilnius |
| Category: | Milling Machines |
| Manufacturer: | UZTS |
| Year of Make: | 1984 |
| Description: | -Width: 4000 mm|-Height: 4000 mm|-Width: 4000 mm|-Length: 12000 mm|Spindle ends according to GOST 836-72: 60|-Number: 13|-T-slot width: 42 mm|-Distance between T-slots: 320 mm|Longitudinal table stroke: 13300 mm|Table feeds with stepless adjustment at milling: 3-3000 mm/min|Speed of rapid table movement: 15000 mm/min|-Vertical: 2|-Horizontal: 1|-Min.: 2130 mm|-Max.: 8460 mm|Max. stroke of slide of milling headstocks: 950 mm|Number of ranges of spindle speeds: 4|Spindle rotation frequency: 5-500 rpm|-Of headstocks: 3-3000 mm/min|-Of slides: 1,5-1500 mm/min|-Of headstocks: 4500 mm/min|-Of slides: 2250 mm/min|Movement speed of traverse: 375 mm/min|-Table (at milling): 24 tons|-Headstocks: 8 tons|-Slides: 3 tons|-Length: 32000 mm|-Width: 14300 mm|-Height from bed base: 11700 mm|-Height above floor level: 10000 mm|Max. work-piece weight: 150 tons|Machine weight (with electrical equipment): 590 tons|Machine weight (without electrical equipment): 560 tons |
| Technical Specifications: | -Width: 4000 mm -Height: 4000 mm -Width: 4000 mm -Length: 12000 mm Spindle ends according to GOST 836-72: 60 -Number: 13 -T-slot width: 42 mm -Distance between T-slots: 320 mm Longitudinal table stroke: 13300 mm Table feeds with stepless adjustment at milling: 3-3000 mm/min Speed of rapid table movement: 15000 mm/min -Vertical: 2 -Horizontal: 1 -Min.: 2130 mm -Max.: 8460 mm Max. stroke of slide of milling headstocks: 950 mm Number of ranges of spindle speeds: 4 Spindle rotation frequency: 5-500 rpm -Of headstocks: 3-3000 mm/min -Of slides: 1,5-1500 mm/min -Of headstocks: 4500 mm/min -Of slides: 2250 mm/min Movement speed of traverse: 375 mm/min -Table (at milling): 24 tons -Headstocks: 8 tons -Slides: 3 tons -Length: 32000 mm -Width: 14300 mm -Height from bed base: 11700 mm -Height above floor level: 10000 mm Max. work-piece weight: 150 tons Machine weight (with electrical equipment): 590 tons Machine weight (without electrical equipment): 560 tons |
