Estarta 301 MV Cylindrical centreless grinding machine
REQUEST PRICE
| Type: | Buy-It-Now |
| Location: | Spain |
| Category: | Centerless Grinders |
| Manufacturer: | Estarta |
| Model: | 301 MV |
| Year of Make: | 2004 |
| Description: | Manufacturer: Estarta |Model: 301MV |Year of manufacturing: 2004 |Type: Centerless |Control Unit : Fanuc|Capacity |Min-max grinding diameter: 1,5-50 mm |In-feed grinding length (max): 125 mm|Grinding wheel head |Grinding wheel dimensions (Outer diameter x Width x Inner diameter): 300x125x175 mm |Regulating wheel dimensions (Outer diameter x Width x Inner diameter): 220x125x125 mm |Grinding wheel outer diameter (min): 220 mm |Regulating wheel outer diameter (min): 165 mm |Grinding wheel peripheral speed: 35 m/s |Regulating wheel speeds: from 10 to 250 min -1 |Diamond regulating wheel height adjuster: +15 / -10 mm |Max grinding and regulating wheel’s profile depth: 8 mm |Max working grinding wheel orientation: 30 |Diamond wheel feed rate: 100-150 mm/min|Motor |Grinding wheel power: 7,5 kW |Regulating wheel power: 0,75 kW|Weight and dimensions |Machine weight : 1.800 kgs |Machine dimensions : 2630x1665x1650 mm|Equipped with |Through feed grinding |Conveyor belt for |
| Technical Specifications: | CNC: Yes Type of CNC: Fanuc Grinding wheel diameter: 220.0 mm Grinding wheel width: 125.0 mm Length x width x height: 2630.0 mm × 1665.0 mm × 1650.0 mm Weight: 1800.0 kg State: good At local norms: --------- |
